LC1390N

Laser Cutting Machine

Electronic lifting

Electronic lifting

The co2 laser cutter machine can automatically adjust the working table to satisfy the demands of cutting different thicknesses materials. The lifting height can reach 20cm.

Automatic Focusing

Auto focusing makes the laser head focus easily and quickly. The co2 laser cutter do not need to adjust the focal length by hand, saving much time and has higher accuracy.

Automatic Focusing
Four Sides Feeding Doors

Four Sides Feeding Doors

LC1390N CO2 laser cutter has four sides feeding material system, you can cut and engrave the material at the largest scale.

Taiwan Hiwin Linear Guide Rail

Adopted Taiwan Hiwin linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time.

Taiwan Hiwin Linear Guide Rail
Japan OMRON Electronic Component

Japan OMRON

Electronic Component

RECI Laser Tube

Higher laser output power density, concentrated light beam, uniformly light spot, high working efficiency, high cutting speed. The laser tube adopts the special manufacturing technique, the laser beam is sharpen after focusing, the mark line is narrow, the scale is deep, the resolution is high, the picture character is clear.

RECI Laser Tube

Technical Parameters

Laser - Type Sealed CO2 laser tube
Laser power 80W 100W 130W 150W 200W (optional)
Cutting Area 1300mm x 900mm
Whole Machine Size 1820* 1310* 1070mm
Cutting Speed 0 - 24,000mm/min
Resetting Positioning Accuracy ±0.05mm
Working Voltage AC 110 -220V±10%, 50-60Hz
Gross Power <1,500W
Operating Temperature 0-45℃
Operating Humidity 5-95%
Minimum Shaping Character English 1x1mm
Work Table 18cm lift platform
Driving System Stepper
Cooling Mode Water-cooling and protection system
Auxiliary Equipments Exhaust-fans, air-exhaust pipe
Controlling Software DSP control system
Compatible Software CorelDraw AutoCAD Photoshop

Application Industry

Wood, organic glass, plastic, garments, paper, leather, rubber, and other nonmetal materials.
